+Engine overview
|
|
|
+===============
|
|
|
+
|
|
|
+
|
|
|
+searx is a `metasearch-engine <https://en.wikipedia.org/wiki/Metasearch_engine>`__,
|
|
|
+so it uses different search engines to provide better results.
|
|
|
+
|
|
|
+Because there is no general search API which could be used for every
|
|
|
+search engine, an adapter has to be built between searx and the
|
|
|
+external search engines. Adapters are stored under the folder
|
|
|
+`searx/engines
|
|
|
+<https://github.com/asciimoo/searx/tree/master/searx/engines>`__.
|
|
|
+
|
|
|
+
|
|
|
+.. contents::
|
|
|
+ :depth: 3
|
|
|
+
|
|
|
+general engine configuration
|
|
|
+----------------------------
|
|
|
+
|
|
|
+It is required to tell searx the type of results the engine provides. The
|
|
|
+arguments can be set in the engine file or in the settings file
|
|
|
+(normally ``settings.yml``). The arguments in the settings file override
|
|
|
+the ones in the engine file.
|
|
|
+
|
|
|
+It does not matter if an option is stored in the engine file or in the
|
|
|
+settings. However, the standard way is the following:
|
|
|
+
|
|
|
+
|
|
|
+engine file
|
|
|
+~~~~~~~~~~~
|
|
|
+
|
|
|
++----------------------+-----------+-----------------------------------------+
|
|
|
+| argument | type | information |
|
|
|
++======================+===========+=========================================+
|
|
|
+| categories | list | pages, in which the engine is working |
|
|
|
++----------------------+-----------+-----------------------------------------+
|
|
|
+| paging | boolean | support multible pages |
|
|
|
++----------------------+-----------+-----------------------------------------+
|
|
|
+| language\_support | boolean | support language choosing |
|
|
|
++----------------------+-----------+-----------------------------------------+
|
|
|
+| time\_range\_support | boolean | support search time range |
|
|
|
++----------------------+-----------+-----------------------------------------+
|
|
|
+| offline | boolean | engine runs offline |
|
|
|
++----------------------+-----------+-----------------------------------------+
|
|
|
+
|
|
|
+settings.yml
|
|
|
+~~~~~~~~~~~~
|
|
|
+
|
|
|
++------------+----------+-----------------------------------------------+
|
|
|
+| argument | type | information |
|
|
|
++============+==========+===============================================+
|
|
|
+| name | string | name of search-engine |
|
|
|
++------------+----------+-----------------------------------------------+
|
|
|
+| engine | string | name of searx-engine (filename without .py) |
|
|
|
++------------+----------+-----------------------------------------------+
|
|
|
+| shortcut | string | shortcut of search-engine |
|
|
|
++------------+----------+-----------------------------------------------+
|
|
|
+| timeout | string | specific timeout for search-engine |
|
|
|
++------------+----------+-----------------------------------------------+
|
|
|
+
|
|
|
+overrides
|
|
|
+~~~~~~~~~
|
|
|
+
|
|
|
+A few of the options have default values in the engine, but are
|
|
|
+often overwritten by the settings. If ``None`` is assigned to an option
|
|
|
+in the engine file, it has to be redefined in the settings,
|
|
|
+otherwise searx will not start with that engine.
|
|
|
+
|
|
|
+The naming of overrides is arbitrary. But the recommended
|
|
|
+overrides are the following:
|
|
|
+
|
|
|
++-----------------------+----------+----------------------------------------------------------------+
|
|
|
+| argument | type | information |
|
|
|
++=======================+==========+================================================================+
|
|
|
+| base\_url | string | base-url, can be overwritten to use same engine on other URL |
|
|
|
++-----------------------+----------+----------------------------------------------------------------+
|
|
|
+| number\_of\_results | int | maximum number of results per request |
|
|
|
++-----------------------+----------+----------------------------------------------------------------+
|
|
|
+| language | string | ISO code of language and country like en\_US |
|
|
|
++-----------------------+----------+----------------------------------------------------------------+
|
|
|
+| api\_key | string | api-key if required by engine |
|
|
|
++-----------------------+----------+----------------------------------------------------------------+
|
|
|
+
|
|
|
+example code
|
|
|
+~~~~~~~~~~~~
|
|
|
+
|
|
|
+.. code:: python
|
|
|
+
|
|
|
+ # engine dependent config
|
|
|
+ categories = ['general']
|
|
|
+ paging = True
|
|
|
+ language_support = True
|
|
|
+
|
|
|
+making a request
|
|
|
+----------------
|
|
|
+
|
|
|
+To perform a search an URL have to be specified. In addition to
|
|
|
+specifying an URL, arguments can be passed to the query.
|
|
|
+
|
|
|
+passed arguments
|
|
|
+~~~~~~~~~~~~~~~~
|
|
|
+
|
|
|
+These arguments can be used to construct the search query. Furthermore,
|
|
|
+parameters with default value can be redefined for special purposes.
|
|
|
+
|
|
|
++----------------------+------------+------------------------------------------------------------------------+
|
|
|
+| argument | type | default-value, information |
|
|
|
++======================+============+========================================================================+
|
|
|
+| url | string | ``''`` |
|
|
|
++----------------------+------------+------------------------------------------------------------------------+
|
|
|
+| method | string | ``'GET'`` |
|
|
|
++----------------------+------------+------------------------------------------------------------------------+
|
|
|
+| headers | set | ``{}`` |
|
|
|
++----------------------+------------+------------------------------------------------------------------------+
|
|
|
+| data | set | ``{}`` |
|
|
|
++----------------------+------------+------------------------------------------------------------------------+
|
|
|
+| cookies | set | ``{}`` |
|
|
|
++----------------------+------------+------------------------------------------------------------------------+
|
|
|
+| verify | boolean | ``True`` |
|
|
|
++----------------------+------------+------------------------------------------------------------------------+
|
|
|
+| headers.User-Agent | string | a random User-Agent |
|
|
|
++----------------------+------------+------------------------------------------------------------------------+
|
|
|
+| category | string | current category, like ``'general'`` |
|
|
|
++----------------------+------------+------------------------------------------------------------------------+
|
|
|
+| started | datetime | current date-time |
|
|
|
++----------------------+------------+------------------------------------------------------------------------+
|
|
|
+| pageno | int | current pagenumber |
|
|
|
++----------------------+------------+------------------------------------------------------------------------+
|
|
|
+| language | string | specific language code like ``'en_US'``, or ``'all'`` if unspecified |
|
|
|
++----------------------+------------+------------------------------------------------------------------------+
|
|
|
+
|
|
|
+parsed arguments
|
|
|
+~~~~~~~~~~~~~~~~
|
|
|
+
|
|
|
+The function ``def request(query, params):`` always returns the
|
|
|
+``params`` variable. Inside searx, the following paramters can be
|
|
|
+used to specify a search request:
|
|
|
+
|
|
|
++------------+-----------+---------------------------------------------------------+
|
|
|
+| argument | type | information |
|
|
|
++============+===========+=========================================================+
|
|
|
+| url | string | requested url |
|
|
|
++------------+-----------+---------------------------------------------------------+
|
|
|
+| method | string | HTTP request method |
|
|
|
++------------+-----------+---------------------------------------------------------+
|
|
|
+| headers | set | HTTP header information |
|
|
|
++------------+-----------+---------------------------------------------------------+
|
|
|
+| data | set | HTTP data information (parsed if ``method != 'GET'``) |
|
|
|
++------------+-----------+---------------------------------------------------------+
|
|
|
+| cookies | set | HTTP cookies |
|
|
|
++------------+-----------+---------------------------------------------------------+
|
|
|
+| verify | boolean | Performing SSL-Validity check |
|
|
|
++------------+-----------+---------------------------------------------------------+
|
|
|
+
|
|
|
+example code
|
|
|
+~~~~~~~~~~~~
|
|
|
+
|
|
|
+.. code:: python
|
|
|
+
|
|
|
+ # search-url
|
|
|
+ base_url = 'https://example.com/'
|
|
|
+ search_string = 'search?{query}&page={page}'
|
|
|
+
|
|
|
+ # do search-request
|
|
|
+ def request(query, params):
|
|
|
+ search_path = search_string.format(
|
|
|
+ query=urlencode({'q': query}),
|
|
|
+ page=params['pageno'])
|
|
|
+
|
|
|
+ params['url'] = base_url + search_path
|
|
|
+
|
|
|
+ return params
|
|
|
+
|
|
|
+returned results
|
|
|
+----------------
|
|
|
+
|
|
|
+Searx is able to return results of different media-types.
|
|
|
+Currently the following media-types are supported:
|
|
|
+
|
|
|
+- default
|
|
|
+- images
|
|
|
+- videos
|
|
|
+- torrent
|
|
|
+- map
|
|
|
+
|
|
|
+To set another media-type as default, the parameter
|
|
|
+``template`` must be set to the desired type.
|
|
|
+
|
|
|
+default
|
|
|
+~~~~~~~
|
|
|
+
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------+
|
|
|
+| result-parameter | information |
|
|
|
++====================+===============================================================================================================+
|
|
|
+| url | string, url of the result |
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------+
|
|
|
+| title | string, title of the result |
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------+
|
|
|
+| content | string, general result-text |
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------+
|
|
|
+| publishedDate | `datetime.datetime <https://docs.python.org/2/library/datetime.html#datetime-objects>`__, time of publish |
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------+
|
|
|
+
|
|
|
+images
|
|
|
+~~~~~~
|
|
|
+
|
|
|
+to use this template, the parameter
|
|
|
+
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| result-parameter | information |
|
|
|
++====================+=======================================================================================================================================+
|
|
|
+| template | is set to ``images.html`` |
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| url | string, url to the result site |
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| title | string, title of the result *(partly implemented)* |
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| content | *(partly implemented)* |
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| publishedDate | `datetime.datetime <https://docs.python.org/2/library/datetime.html#datetime-objects>`__, time of publish *(partly implemented)* |
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| img\_src | string, url to the result image |
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| thumbnail\_src | string, url to a small-preview image |
|
|
|
++--------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+
|
|
|
+videos
|
|
|
+~~~~~~
|
|
|
+
|
|
|
++--------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| result-parameter | information |
|
|
|
++====================+==============================================================================================================+
|
|
|
+| template | is set to ``videos.html`` |
|
|
|
++--------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| url | string, url of the result |
|
|
|
++--------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| title | string, title of the result |
|
|
|
++--------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| content | *(not implemented yet)* |
|
|
|
++--------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| publishedDate | `datetime.datetime <https://docs.python.org/2/library/datetime.html#datetime-objects>`__, time of publish |
|
|
|
++--------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| thumbnail | string, url to a small-preview image |
|
|
|
++--------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+
|
|
|
+torrent
|
|
|
+~~~~~~~
|
|
|
+
|
|
|
++------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| result-parameter | information |
|
|
|
++==================+=======================================================================================================================================+
|
|
|
+| template | is set to ``torrent.html`` |
|
|
|
++------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| url | string, url of the result |
|
|
|
++------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| title | string, title of the result |
|
|
|
++------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| content | string, general result-text |
|
|
|
++------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| publishedDate | `datetime.datetime <https://docs.python.org/2/library/datetime.html#datetime-objects>`__, time of publish *(not implemented yet)* |
|
|
|
++------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| seed | int, number of seeder |
|
|
|
++------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| leech | int, number of leecher |
|
|
|
++------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| filesize | int, size of file in bytes |
|
|
|
++------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| files | int, number of files |
|
|
|
++------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| magnetlink | string, `magnetlink <https://en.wikipedia.org/wiki/Magnet_URI_scheme>`__ of the result |
|
|
|
++------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+| torrentfile | string, torrentfile of the result |
|
|
|
++------------------+---------------------------------------------------------------------------------------------------------------------------------------+
|
|
|
+
|
|
|
+
|
|
|
+map
|
|
|
+~~~
|
|
|
+
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| result-parameter | information |
|
|
|
++=========================+==============================================================================================================+
|
|
|
+| url | string, url of the result |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| title | string, title of the result |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| content | string, general result-text |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| publishedDate | `datetime.datetime <https://docs.python.org/2/library/datetime.html#datetime-objects>`__, time of publish |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| latitude | latitude of result (in decimal format) |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| longitude | longitude of result (in decimal format) |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| boundingbox | boundingbox of result (array of 4. values ``[lat-min, lat-max, lon-min, lon-max]``) |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| geojson | geojson of result (http://geojson.org) |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| osm.type | type of osm-object (if OSM-Result) |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| osm.id | id of osm-object (if OSM-Result) |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| address.name | name of object |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| address.road | street name of object |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| address.house\_number | house number of object |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| address.locality | city, place of object |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| address.postcode | postcode of object |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+| address.country | country of object |
|
|
|
++-------------------------+--------------------------------------------------------------------------------------------------------------+
|
|
|
+
|
