+.. _engines-dev:
|
|
|
+
|
|
|
+===============
|
|
|
+Engine overview
|
|
|
+===============
|
|
|
+
|
|
|
+.. _metasearch-engine: https://en.wikipedia.org/wiki/Metasearch_engine
|
|
|
+
|
|
|
+searx is a metasearch-engine_, so it uses different search engines to provide
|
|
|
+better results.
|
|
|
+
|
|
|
+Because there is no general search API which could be used for every search
|
|
|
+engine, an adapter has to be built between searx and the external search
|
|
|
+engines. Adapters are stored under the folder :origin:`searx/engines`.
|
|
|
+
|
|
|
+.. contents::
|
|
|
+ :depth: 3
|
|
|
+ :backlinks: entry
|
|
|
+
|
|
|
+general engine configuration
|
|
|
+============================
|
|
|
+
|
|
|
+It is required to tell searx the type of results the engine provides. The
|
|
|
+arguments can be set in the engine file or in the settings file
|
|
|
+(normally ``settings.yml``). The arguments in the settings file override
|
|
|
+the ones in the engine file.
|
|
|
+
|
|
|
+It does not matter if an option is stored in the engine file or in the
|
|
|
+settings. However, the standard way is the following:
|
|
|
+
|
|
|
+
|
|
|
+engine file
|
|
|
+-----------
|
|
|
+
|
|
|
+======================= =========== ===========================================
|
|
|
+argument type information
|
|
|
+======================= =========== ===========================================
|
|
|
+categories list pages, in which the engine is working
|
|
|
+paging boolean support multible pages
|
|
|
+language_support boolean support language choosing
|
|
|
+time_range_support boolean support search time range
|
|
|
+offline boolean engine runs offline
|
|
|
+======================= =========== ===========================================
|
|
|
+
|
|
|
+
|
|
|
+settings.yml
|
|
|
+------------
|
|
|
+
|
|
|
+======================= =========== ===========================================
|
|
|
+argument type information
|
|
|
+======================= =========== ===========================================
|
|
|
+name string name of search-engine
|
|
|
+engine string name of searx-engine
|
|
|
+ (filename without ``.py``)
|
|
|
+shortcut string shortcut of search-engine
|
|
|
+timeout string specific timeout for search-engine
|
|
|
+======================= =========== ===========================================
|
|
|
+
|
|
|
+
|
|
|
+overrides
|
|
|
+---------
|
|
|
+
|
|
|
+A few of the options have default values in the engine, but are often
|
|
|
+overwritten by the settings. If ``None`` is assigned to an option in the engine
|
|
|
+file, it has to be redefined in the settings, otherwise searx will not start
|
|
|
+with that engine.
|
|
|
+
|
|
|
+The naming of overrides is arbitrary. But the recommended overrides are the
|
|
|
+following:
|
|
|
+
|
|
|
+======================= =========== ===========================================
|
|
|
+argument type information
|
|
|
+======================= =========== ===========================================
|
|
|
+base_url string base-url, can be overwritten to use same
|
|
|
+ engine on other URL
|
|
|
+number_of_results int maximum number of results per request
|
|
|
+language string ISO code of language and country like en_US
|
|
|
+api_key string api-key if required by engine
|
|
|
+======================= =========== ===========================================
|
|
|
+
|
|
|
+example code
|
|
|
+------------
|
|
|
+
|
|
|
+.. code:: python
|
|
|
+
|
|
|
+ # engine dependent config
|
|
|
+ categories = ['general']
|
|
|
+ paging = True
|
|
|
+ language_support = True
|
|
|
+
|
|
|
+
|
|
|
+making a request
|
|
|
+================
|
|
|
+
|
|
|
+To perform a search an URL have to be specified. In addition to specifying an
|
|
|
+URL, arguments can be passed to the query.
|
|
|
+
|
|
|
+passed arguments
|
|
|
+----------------
|
|
|
+
|
|
|
+These arguments can be used to construct the search query. Furthermore,
|
|
|
+parameters with default value can be redefined for special purposes.
|
|
|
+
|
|
|
+====================== ============ ========================================================================
|
|
|
+argument type default-value, information
|
|
|
+====================== ============ ========================================================================
|
|
|
+url string ``''``
|
|
|
+method string ``'GET'``
|
|
|
+headers set ``{}``
|
|
|
+data set ``{}``
|
|
|
+cookies set ``{}``
|
|
|
+verify boolean ``True``
|
|
|
+headers.User-Agent string a random User-Agent
|
|
|
+category string current category, like ``'general'``
|
|
|
+started datetime current date-time
|
|
|
+pageno int current pagenumber
|
|
|
+language string specific language code like ``'en_US'``, or ``'all'`` if unspecified
|
|
|
+====================== ============ ========================================================================
|
|
|
+
|
|
|
+parsed arguments
|
|
|
+----------------
|
|
|
+
|
|
|
+The function ``def request(query, params):`` always returns the ``params``
|
|
|
+variable. Inside searx, the following paramters can be used to specify a search
|
|
|
+request:
|
|
|
+
|
|
|
+============ =========== =========================================================
|
|
|
+argument type information
|
|
|
+============ =========== =========================================================
|
|
|
+url string requested url
|
|
|
+method string HTTP request method
|
|
|
+headers set HTTP header information
|
|
|
+data set HTTP data information (parsed if ``method != 'GET'``)
|
|
|
+cookies set HTTP cookies
|
|
|
+verify boolean Performing SSL-Validity check
|
|
|
+============ =========== =========================================================
|
|
|
+
|
|
|
+
|
|
|
+example code
|
|
|
+------------
|
|
|
+
|
|
|
+.. code:: python
|
|
|
+
|
|
|
+ # search-url
|
|
|
+ base_url = 'https://example.com/'
|
|
|
+ search_string = 'search?{query}&page={page}'
|
|
|
+
|
|
|
+ # do search-request
|
|
|
+ def request(query, params):
|
|
|
+ search_path = search_string.format(
|
|
|
+ query=urlencode({'q': query}),
|
|
|
+ page=params['pageno'])
|
|
|
+
|
|
|
+ params['url'] = base_url + search_path
|
|
|
+
|
|
|
+ return params
|
|
|
+
|
|
|
+
|
|
|
+returned results
|
|
|
+================
|
|
|
+
|
|
|
+Searx is able to return results of different media-types. Currently the
|
|
|
+following media-types are supported:
|
|
|
+
|
|
|
+- default_
|
|
|
+- images_
|
|
|
+- videos_
|
|
|
+- torrent_
|
|
|
+- map_
|
|
|
+
|
|
|
+To set another media-type as default, the parameter ``template`` must be set to
|
|
|
+the desired type.
|
|
|
+
|
|
|
+default
|
|
|
+-------
|
|
|
+
|
|
|
+========================= =====================================================
|
|
|
+result-parameter information
|
|
|
+========================= =====================================================
|
|
|
+url string, url of the result
|
|
|
+title string, title of the result
|
|
|
+content string, general result-text
|
|
|
+publishedDate :py:class:`datetime.datetime`, time of publish
|
|
|
+========================= =====================================================
|
|
|
+
|
|
|
+images
|
|
|
+------
|
|
|
+
|
|
|
+To use this template, the parameter:
|
|
|
+
|
|
|
+========================= =====================================================
|
|
|
+result-parameter information
|
|
|
+========================= =====================================================
|
|
|
+template is set to ``images.html``
|
|
|
+url string, url to the result site
|
|
|
+title string, title of the result *(partly implemented)*
|
|
|
+content *(partly implemented)*
|
|
|
+publishedDate :py:class:`datetime.datetime`,
|
|
|
+ time of publish *(partly implemented)*
|
|
|
+img\_src string, url to the result image
|
|
|
+thumbnail\_src string, url to a small-preview image
|
|
|
+========================= =====================================================
|
|
|
+
|
|
|
+videos
|
|
|
+------
|
|
|
+
|
|
|
+========================= =====================================================
|
|
|
+result-parameter information
|
|
|
+========================= =====================================================
|
|
|
+template is set to ``videos.html``
|
|
|
+url string, url of the result
|
|
|
+title string, title of the result
|
|
|
+content *(not implemented yet)*
|
|
|
+publishedDate :py:class:`datetime.datetime`, time of publish
|
|
|
+thumbnail string, url to a small-preview image
|
|
|
+========================= =====================================================
|
|
|
+
|
|
|
+torrent
|
|
|
+-------
|
|
|
+
|
|
|
+.. _magnetlink: https://en.wikipedia.org/wiki/Magnet_URI_scheme
|
|
|
+
|
|
|
+========================= =====================================================
|
|
|
+result-parameter information
|
|
|
+========================= =====================================================
|
|
|
+template is set to ``torrent.html``
|
|
|
+url string, url of the result
|
|
|
+title string, title of the result
|
|
|
+content string, general result-text
|
|
|
+publishedDate :py:class:`datetime.datetime`,
|
|
|
+ time of publish *(not implemented yet)*
|
|
|
+seed int, number of seeder
|
|
|
+leech int, number of leecher
|
|
|
+filesize int, size of file in bytes
|
|
|
+files int, number of files
|
|
|
+magnetlink string, magnetlink_ of the result
|
|
|
+torrentfile string, torrentfile of the result
|
|
|
+========================= =====================================================
|
|
|
+
|
|
|
+
|
|
|
+map
|
|
|
+---
|
|
|
+
|
|
|
+========================= =====================================================
|
|
|
+result-parameter information
|
|
|
+========================= =====================================================
|
|
|
+url string, url of the result
|
|
|
+title string, title of the result
|
|
|
+content string, general result-text
|
|
|
+publishedDate :py:class:`datetime.datetime`, time of publish
|
|
|
+latitude latitude of result (in decimal format)
|
|
|
+longitude longitude of result (in decimal format)
|
|
|
+boundingbox boundingbox of result (array of 4. values
|
|
|
+ ``[lat-min, lat-max, lon-min, lon-max]``)
|
|
|
+geojson geojson of result (http://geojson.org)
|
|
|
+osm.type type of osm-object (if OSM-Result)
|
|
|
+osm.id id of osm-object (if OSM-Result)
|
|
|
+address.name name of object
|
|
|
+address.road street name of object
|
|
|
+address.house_number house number of object
|
|
|
+address.locality city, place of object
|
|
|
+address.postcode postcode of object
|
|
|
+address.country country of object
|
|
|
+========================= =====================================================
|
